HX36B Automatic Notebook Elastic Band Fixing Machine Applies And Fixes Elastic Bands On The Notebook

Name: HX36B Automatic Notebook Elastic Band Fixing Machine Applies And Fixes Elastic Bands On The Notebook
Brand: HXCP
Price: 1 USD

Model Number : HX36B

Packaging Details : Stretch Film with Wooden Case

Distance from Hole to Cover Edge Side : 0-40mm

Working Speed : 2000pcs/h

Cover Thickness : 0.7-7mm

Dimensions : 1600×930×1385(L×W×H)

Power : 8KW

Elastic Band Length : 0-160mm

Width of Elastic Band : 6-10mm

MOQ : 1 set

Voltage : 220V

Brand Name : HXCP

Distance between 2 Holes : 40-271mm

Weight : 310KG

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 10 sets/month

Delivery Time : 30 work days

Min Cover Size : 70×100mm(W×L)

Place of Origin : China

Max Cover Size : 300×420mm(W×L)

Distance from Hole to Upper and Bottom Side : 9-100mm

Certification : CE

Contact Now

HX36B Automatic Notebook Elastic Band Fixing Machine

HX36B Automatic Notebook Elastic Band Fixing Machine Applies And Fixes Elastic Bands On The Notebook
Description

HX36B Automatic Notebook Elastic Band Fixing Machine applies and fixes elastic bands on the notebook cover fully automatically. It handles feeding, punching, threading, cutting, gluing, fixing, and stacking – all within a compact footprint. Powered by servo motors, this highly automated machine ensures efficient, stable operation with minimal downtime, achieving over 10 times the output of manual production. Operators can store and recall 10 job settings for rapid setup changes between runs. Works on hardcovers, softcovers, and pre-cased notebooks. Easily switches to semi-auto mode for manual feeding when for smaller batches or testing.

Parameters

Model	HX36B
Min Cover Size	70×100mm(W×L)
Max Cover Size	300×420mm(W×L)
Working Speed	2000pcs/h
Distance between 2 Holes	40-271mm
Distance from Hole to Upper and Bottom Side	9-100mm
Distance from Hole to Cover Edge Side	0-40mm
Elastic Band Length	0-160mm
Cover Thickness	0.7-7mm
Width of Elastic Band	6-10mm
Dimensions	1600×930×1385(L×W×H)
Power	8KW
Voltage	220V
Weight	310KG

Products Show

HX36B Automatic Notebook Elastic Band Fixing Machine Applies And Fixes Elastic Bands On The Notebook

Details

HX36B Automatic Notebook Elastic Band Fixing Machine Applies And Fixes Elastic Bands On The Notebook

FAQ:

Q: What is the brand name of this product?

A: The brand name of this product is HXCP.

Q: Does this product come with any certification?

A: Yes, this product is CE certified.

Q: Where is this product manufactured?

A: This product is manufactured in China.

Q: What is the minimum order quantity for this product?

A: The minimum order quantity for this product is 1 set.

Q: What are the payment terms for this product?

A: The payment terms for this product are L/C, D/A, D/P, T/T, Western Union, and MoneyGram.

Q: What is the supply ability for this product?

A: The supply ability for this product is 10 sets per month.

Q: What is the delivery time for this product?

A: The delivery time for this product is 30 work days.

Q: How is this product packaged?

A: This product is packaged with stretch film and a wooden case.
